Danfoss VLT CANopen MCA 105 Service Guide

e30bc565.10
1
2
3
4
4
4
56
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate stando
4 Midplate screw
5 DC(-) plate stando
6 DC(-) plate screw
Table 10.5
Illustration 10.16 Standard 4-Capacitor Layout
e30bc566.10
1
2
2
344
444
566
1 DC(+) plate stando
2 DC(+) plate screw
3 Midplate stando
4 Midplate screw
5 DC(-) plate stando
6 DC(-) plate screw
Table 10.6
Illustration 10.17 Standard 6-Capacitor Layout
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 163
10 10
