e30bg854.10
6
1 Balance/high-frequency card 7 Insulator sheet 3
2 DC(-) plate 8 Plug
3 Midplate 9 Twistlock DC capacitor
4 DC(+) plate 10 O-ring gasket
5 Insulator sheet 1 11 Capacitor housing
6 Insulator sheet 2 12 Housing gasket
Illustration 10.18 Twistlock DC Capacitor Bank, 240/400 V AC Unit
D1h/D3h/D5h/D6h/J8 Drive Di... Service Guide
MG94A502 Danfoss A/S © 02/2019 All rights reserved. 165
10 10
