1 Screw (T20) 7 Alignment tab
2 Inrush card 8 Nut (7 mm)
3 Rectier(+) bus plate 9 Inrush busbars
4 Connection point for load share/regen (optional) 10 MK109: SCR gate
5 Inrush card frame 11 MK110: Signals to power card (MK105) and fan power card
(MK1200)
6 Rectier(-) bus plate 12 Connection point for load share/regen (optional)
Illustration 13.5 Inrush Card and Inrush Card Frame
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
270 Danfoss A/S © 02/2019 All rights reserved. MG94A502
