Danfoss VLT CANopen MCA 105 Service Guide

130BF843.10
1
4
3
5
6
10
2
7
8
9
1 Nut (13 mm) 6 Lower nut (13 mm)
2 Current sensor 7 Current sensor cable connector
3 Current sensor busbar 8 Screw (T20)
4 Screw (T25) 9 Heat sink fan housing
5 Left motor busbar 10 Right motor busbar
Illustration 13.14 Current Sensors
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
288 Danfoss A/S © 02/2019 All rights reserved. MG94A502
