Danfoss VLT CANopen MCA 105 Service Guide

1
130BF841.10
6
2
5
4
3
8
7
1 Top horizontal brake busbar 5 Bottom horizontal brake busbar
2 Thread-forming screw (T20) 6 Middle horizontal brake busbar
3 Screw (T40) 7 Nut (13 mm)
4 Snubber capacitor 8 Vertical brake busbars
Illustration 13.32 Horizontal Brake Busbars in E1h/E3h Drives
E1h–E4h Drive Disassembly a...
VLT
®
FC Series, D1h–D8h, Da2/Db2/Da4/Db4, E1h–E4h, J8/J9
314 Danfoss A/S © 02/2019 All rights reserved. MG94A502
