Par. No.
#
Parameter description Default value 4-set-up FC 302
only
Change during
operation
Conver-
sion index
Type
33-5* I/O Configuration
33-50 Terminal X57/1 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-51 Terminal X57/2 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-52 Terminal X57/3 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-53 Terminal X57/4 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-54 Terminal X57/5 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-55 Terminal X57/6 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-56 Terminal X57/7 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-57 Terminal X57/8 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-58 Terminal X57/9 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-59 Terminal X57/10 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-60 Terminal X59/1 and X59/2 Mode [1] Output 2 set-ups FALSE - Uint8
33-61 Terminal X59/1 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-62 Terminal X59/2 Digital Input [0] No function 2 set-ups TRUE - Uint8
33-63 Terminal X59/1 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-64 Terminal X59/2 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-65 Terminal X59/3 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-66 Terminal X59/4 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-67 Terminal X59/5 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-68 Terminal X59/6 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-69 Terminal X59/7 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-70
Terminal X59/8 Digital Output [0] No function 2 set-ups TRUE - Uint8
33-8* Global Parameters
33-80 Activated Program Number -1 N/A 2 set-ups TRUE 0 Int8
33-81 Power-up State [1] Motor ON 2 set-ups TRUE - Uint8
33-82 Drive Status Monitoring [1] On 2 set-ups TRUE - Uint8
33-83 Behavior After Error [0] Coast 2 set-ups TRUE - Uint8
33-84 Behavior afterEsc. [0] Controlled stop 2 set-ups TRUE - Uint8
33-85 MCO Supplied by External 24VDC [0] No 2 set-ups TRUE - Uint8
VLT
®
Automation Drive FC 300
Instruction Manual High Power
4. How to Program
MG.33.U1.22 - VLT
®
is a registered Danfoss trademark.
109
