Table 51: Option C1 Terminal Connections for VLT® Extended Relay Card MCB 113
Option card terminal
Corresponding terminal within the control compartment
X45.1
XDF.17
X45.2
XDF.18
X45.3
XDF.19
X45.4
XDF.20
X46.1
XDF.1
X46.2
XDF.2
X46.3
XDF.3
X46.4
XDF.4
X46.5
XDF.5
X46.6
XDF.6
X46.7
XDF.7
X46.8
XDF.8
X46.9
XDF.9
X46.10
XDF.10
X46.11
XDF.11
X46.12
XDF.12
X46.13
XDF.13
X46.14
XDF.14
X47.1
XDF.21
X47.2
XDF.22
X47.3
XDF.23
X47.4
XDF.24
X47.5
XDF.25
X47.6
XDF.26
X47.7
XDF.27
X47.8
XDF.28
X47.9
XDF.29
X47.10
XDF.30
X47.11
XDF.31
X47.12
XDF.32
X58.1
XDF.15
X58.2
XDF.16
AQ357954340588en-000201 / 130R0881 | 73Danfoss A/S © 2020.09
Electrical Installation
VLT® Refrigeration Drive FC 103
Operating Guide
