VLT
®
FCD Series
direction of rotation does not respond to the revers-
ing signal (negative reference), the reference will be
set to 0.
Shifting from Local operation to Remote operation in
parameter 002 Local/remote control, while this pa-
rameter has been set to Remote-operated control
and open loop [1]: The configuration selected in pa-
rameter 100 Configuration will be active. The shift
will be smooth.
Shifting from Remote control to Local control in
parameter 002 Local/remote operation, while this pa-
rameter has been set to Remote-operated control as
parameter 100 [4]: the present reference will be
maintained. If the reference signal is negative, the
local reference will be set to 0.
Shifting from Local operation to Remote operation in
parameter 002 Local/remote operation, while this pa-
rameter has been set to Remote operation: The
local reference will be replaced by the remote-
operated reference signal.
014
014 Local stop
(LOCAL STOP)
Value:
Not active (DISABLE)
[0]
✭Active (ENABLE)
[1]
Function:
In this parameter, the local [STOP]-key can be en-
gaged or disengaged on the control panel and on
the LCP control panel.
Description of choice:
If Not active [0] is selected in this parameter, the
[STOP]-key will be inactive.
NB!:
If Not active [0] is selected, the motor can-
not be stopped by means of the [STOP]-key.
015
015 Local jog
(LOCAL JOGGING)
Value:
✭Not active (DISABLE)
[0]
Active (ENABLE)
[1]
Function:
In this parameter, the jog function on the LCP con-
trol panel can be engaged/disengaged.
Description of choice:
If Not active [0] is selected in this parameter, the
[JOG]-key will be inactive.
016
016 Local reversing
(LOCAL REVERSING)
Value:
✭Not active (DISABLE)
[0]
Active (ENABLE)
[1]
Function:
In this parameter you can select/deselect the revers-
ing function on the LCP control panel. The key can
only be used if parameter 002 Local/remote opera-
tion is set to Local operation [1] and parameter 013
Localcontrol to Local control, open loop [1] or Local
control as parameter 100 [3].
Description of choice:
If Disable [0] is selected in this parameter, the [FWD/
REV] key will be disabled. See also parameter 200
Output frequency range.
017
017 Local reset of trip
(LOCAL RESET)
Value:
Not active (DISABLE)
[0]
✭Active (ENABLE)
[1]
Function:
In this parameter, the reset function on the control
panel can be engaged/disengaged.
Description of choice:
If Not active [0] is selected in this parameter, the re-
set function will be inactive.
NB!:
Select Not active [0], only if an external reset
signal has been connected via the digital in-
puts.
018
018 Lock for data changes
(DATA CHANGE LOCK)
Value:
✭Not locked (NOT LOCKED)
[0]
Locked (LOCKED)
[1]
Function:
In this parameter, it is possible to ’lock’ the controls
to disable data changes via the control keys.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
MG.04.A1.02 - VLT is a registered Danfoss trade mark
53
Programming
