Description of choice:
The Quick Menu is set up as follows:
1. Select parameter 025 Quick Menu setup and
press [CHANGE DATA].
2. Index 1 indicates the first parameter in Quick
Menu. You can scroll between the index numbers
using the [+ / -] keys. Select Index 1.
3. Using [< >] you can scroll between the three fig-
ures. Press the [<] key once ad the last number
in the parameter number can be selected using
the [+ / -] keys.
Set Index 1 to 100 for parameter 100 Configura-
tion.
4. Press [OK] when Index 1 has been set to 100.
5. Repeat steps 2 - 4 until all parameters required
have been set to the Quick Menu key.
6. Press [OK] to complete the Quick Menu setup.
If parameter 100 Configuration is selected at Index
1, Quick Menu will start with this parameter every
time Quick Menu is activated.
Please note that parameter 024 User-defined Quick
Menu and parameter 025 Quick Menu setup are re-
set to the factory setting during initialisation.
026
026 LED Status
(LED STATUS)
Value:
Overload (OVERLOAD)
[0]
Therm. warn/alarm 36 (OVERTEMP)
[1]
Thermistor/ETR (THERMAL MOTOR)
[2]
Digital input 18 (DIGIT AL INPUT 18)
[3]
Digital input 19 (DIGIT AL INPUT 19)
[4]
Digital input 27 (DIGIT AL INPUT 27)
[5]
Digital input 29 (DIGIT AL INPUT 29)
[6]
Digital input 33 (DIGIT AL INPUT 33)
[7]
As relay par. 323 (AS RELAY / P323)
[8]
As dig.outp. par.341 (AD DIG. OUT. / P341)
[9]
As mech.brake output
(AS MECH. BRAKE OUTPUT)
[10]
Function:
This parameter enables the user to visualize differ-
ent situations using the Status LED.
Description of choice:
Select the function to be visualized.
✭ = factory setting. () = display text [] = value for use in communication via serial communication port
