Programming
Hex Fault messages
00000002 Trip lock
00000040 HPFB timeout
00000080 Standard bus timeout
00000100 Short circuit
00000200 24 V supply fault
00000400 Earth fault
00000800 Overcurrent
00004000 Motor thermistor
00008000 Inverter overload
00010000 Undervoltage
00020000 Overvoltage
00040000 Phase loss
00080000 Live zero error
00100000 Overtemperature
02000000 HPFB error
08000000 Inrush fault
10000000 Internal error
NB!:
This parameter is updated every 20 ms.
539 Data read-out: Control word
(CONTROL WORD)
Value:
Unit
Function:
This parameter can be read out via the serial
communication port.
Description of choice:
Indicates the control word sent via the serial
communication port in Hex code from the FC motor.
This parameter is updated every 20 ms.
540 Data read-out: Warning word
(WARN. WORD)
Value:
Unit
Function:
This parameter can be read out via the
serial communication port. See chapter on
"Warnings and alarms".
Description of choice:
States in Hex format whether there is a
warning on the FC motor.
Hex Warning messages
00000008 HPFB timeout
00000010 Standard bus timeout
00000040 Current limit
00000200 Inverter overload
00001000 Voltage warning low
00002000 Voltage warning high
00004000 Phase loss
00010000 Live zero error warning
00400000 Output freq. limit warning
00800000 HPFB error
40000000 24 V supply warning
80000000 Inverter temp. high
541 Data read-out: Extended status word
(STATUS WORD)
Value:
Unit
Function:
This parameter can be read out via the serial
communication port.
Description of choice:
States in Hex format whether there is a
warning on the FC motor.
Hex Status messages
01 Ramping
04 Start clockwise/counterclock-
wise
08 Slow down
10 Catch-up
8000 Frequency limit
542 Data read-out: Terminal 1, analogue input
(ANALOG INPUT 1)
Value:
Unit: mA
Function:
This parameter can be read out via the serial
communi
cation port.
Descri
ption of choice:
The value shown indicates the signal value on terminal 1.
The scaling (parameters 336 and 337) does not
influence the read-out. Min. and max. are determined
by the offset and gain adjustment of the AD-converter.
✭
= factory setting. () = display text [] = value for use in communication via serial communication port
