Danfoss VLT series Design Guide

1.1.5. Abbreviations
Alternating current AC
American wire gauge AWG
Ampere/AMP A
Automatic Motor Adaptation AMA
Current limit I
LIM
Degrees Celsius °C
Direct current DC
Drive Dependent D-TYPE
Electro Magnetic Compatibility EMC
Electronic Thermal Relay ETR
drive FC
Gram g
Hertz Hz
Kilohertz kHz
Local Control Panel LCP
Meter m
Millihenry Inductance mH
Milliampere mA
Millisecond ms
Minute min
Motion Control Tool MCT
Nanofarad nF
Newton Meters Nm
Nominal motor current I
M,N
Nominal motor frequency f
M,N
Nominal motor power P
M,N
Nominal motor voltage U
M,N
Parameter par.
Protective Extra Low Voltage PELV
Printed Circuit Board PCB
Rated Inverter Output Current I
INV
Revolutions Per Minute RPM
Second s
Torque limit T
LIM
Volt V
1.1.6. Definitions
Drive:
I
VLT,MAX
The maximum output current.
I
VLT,N
The rated output current supplied by the adjustable frequency drive.
U
VLT, MAX
The maximum output voltage.
Input:
Control command
You can start and stop the connected motor using
the LCP and the digital inputs.
Functions are divided into two groups.
Functions in group 1 have higher priority than
functions in group 2.
Group 1
Reset, Coasting stop, Reset and Coasting
stop, Quick stop, DC braking, Stop and the
"Off" key.
Group 2
Start, Pulse start, Reversing, Start reversing,
Jog and Freeze output
VLT
®
HVAC Drive Design Guide 1. How to Read this Design Guide
MG.11.B4.22 - VLT
®
is a registered Danfoss trademark. 7
1

Danfoss VLT series Specifications

General

Series	VLT
Category	DC Drives
Output Voltage	0-100% of input voltage
Protection Features	Overvoltage, Undervoltage, Overcurrent, Overtemperature, Short Circuit, Ground Fault
Communication Interfaces	Profibus, CANopen
Enclosure Rating	IP20, IP21, IP55, IP66
Cooling Method	Forced Air Cooling, Convection Cooling
Control Mode	Sensorless Vector, Closed Loop Vector
Ambient Temperature	-10°C to +50°C (14°F to 122°F)
