Chapter 1: Introduction
4
User
Guide
Figure 1-2: Receiver Model Numbers
Figure 1-3: Transmitter Model Numbers
U R - 4 D 420 - R0 - 000
Bands:
V = VHF
U = UHF
Functional
Capabilities:
00 = Repeater (MT-4R only)
R0 = Repeater
B0 = Base, no encryption
B1 = Base, DES-OFB and AES encryption
MT-4 P25 RECEIVERS
EXAMPLE: UR-4D420-R0-000
MT-4 UHF P25 Receiver, MT-4D series, (406-430 MHz),
Repeater functionality, no added options
MT-4 Series:
R = MT-4R
D = MT-4D
E = MT-4E
Range Within Band:
VHF/150:
150 = 136 - 174 MHz
UHF/400:
420 = 406 - 430 MHz
460 = 450 - 470 MHz
Options:
000 = None (Standard)
V T - 4 D 160 - B0 - 8
Bands:
V = VHF
U = UHF
Functional
Capabilities:
00 = Repeater (MT-4R only)
R0 = Repeater
B0 = Base, no encryption
B1 = Base, DES-OFB and AES encryption
MT-4 P25 TRANSMITTERS
EXAMPLE: VT-4D160-B0-800
MT-4 VHF P25 Transmitter, MT-4D series, (150-174 MHz),
Base functionality (no encryption), 8 Watts, no added options
MT-4 Series:
R = MT-4R
D = MT-4D
E = MT-4E
Range Within Band:
VHF/150:
140 = 136 - 150 MHz
160 = 150 - 174 MHz
UHF/400:
420 = 406 - 430 MHz
460 = 450 - 470 MHz
Options:
00 = None (Standard)
RF Power
Output:
2 = 2 Watts
8 = 8 Watts
