CHAPTER 4: P25 SYSTEM
BLOCK DIAGRAMS
This chapter contains sample block diagrams of mixed mode repeater
and base station systems. Not all blocks of the receivers and
transmitters are shown (such as the receiver front end or transmitter
amplifi er). These blocks are shown to give a basic understanding of
the signal fl ow through a Daniels repeater or base station. Although
mixed mode systems are shown, analog only or P25 digital only can
be programmed in the receiver or transmitter.
