UG-001 Daniels P25 Radio Systems
www.danelec.com
Chapter 6: Radio System Components
35
User
Guide
CHAPTER 6: RADIO SYSTEM COMPONENTS
DANIELS P25 RADIO SYSTEM COMPONENTS
A Daniels P25 Radio System consists of:
- P25 Receiver and Transmitter modules (MT-4R, MT-4D Repeater, MT-4D Base, MT-4E)
- P25 controller (CI-RC-4L, CI-RC-4M, CI-BC-4E)
- RSS Software and Programming Interface Cable
- Subrack (with Optional Auxiliary Connector)
- System Monitor
- Power Amplifi ers
- Tuning and Maintenance Tools
The Receiver, Transmitter, Controller, Software and Programming cable were discussed previously.
The other radio system components are further explained in greater detail in this chapter.
All Daniels modules are hot swappable. There is no need to disconnect the power supply when inserting
or removing the modules from the subrack. All transmitters and power amplifi ers are rated for 100%
continuous duty.
