Dantherm AC-M5 W MKII User Manual

3
062367 • Version 1.0 • 14.02.2011
Introduction
Overview
Introduction
This is the service manual for the Dantherm Air Handling A/S AC-M5 W MKII unit.
The below table of contents gives an overview of the main sections.
Serial number
This manual covers units with serial numbers equal or higher than:
XXXXXX1158513
Syntax
Please note that this unit comes as standard with a 2 KW heating element installed:
Dantherm number Code
*)
NATO stock number
322036 AC-M5WE-H020-B-BS381C285 -
*)
The code is specified on the data plate, which is placed on the outside of the unit. See
the explanation of the syntax code on page 5
Warning
It is the responsibility of the operator to read and understand this service manual
and other information provided and to use the correct operating procedures.
Air conditioners should only be operated by qualified (trained) personnel and the repair
of the cooling circuit and electrical system is to be done only by skilled service people.
Failure to do so can result in personal injury or equipment damage.
Read the entire manual before the initial start-up of the air conditioner. It is important to
know the correct operating procedures for the air conditioner and all safety precautions
to prevent the possibility of property damage and/or personal injury.
Table of contents
This service manual covers the following main topics:
Topic See page
General information 4
Syntax 5
Product description 6
Functional description 15
User’s guide 16
Service guide 25
Technical information 36

Dantherm AC-M5 W MKII Specifications

General

Brand	Dantherm
Model	AC-M5 W MKII
Category	Air Handlers
Language	English
