Dantherm HPP-iw Series - Page 37

37
1007332 ISSUE 5
MODEL UNITS HPP-iw 12 HPP-iw 16 HPP-iw 22 HPP-iw 28
PERFORMANCE CONDITION: Air 27°C/Water 27°C/RH 80%
Heating capacity kW 15.0 21.0 27.5 36.0
COP range 15.0-6.6 14.8-6.4 15.0-6.8 14.8-6.0
Average COP at 50% Speed 10.6 10.3 10.3 10.2
PERFORMANCE CONDITION: Air 15°C/Water 26°C/RH 70%
Heating capacity kW 10.5 14.5 18.0 23.9
COP range 7.7-4.6 7.1-4.6 7.5-4.6 7.5-4.6
Average COP at 50% Speed 6.4 6.3 6.3 6.3
PERFORMANCE CONDITION: Air 35°C/Water 28°C/RH 80%
Cooling capacity
kW 6.7 9.5 11.9 16.0
TECHNICAL SPECIFICATIONS
Operating air temperature °C -10°C to 43°C
Water heat temperature set range °C 18°C to 40°C
Water cool temperature set range °C 12°C to 30°C
POWER SUPPLY 230V Single Phase 50Hz 400V Three Phase 50Hz
Rated input power kW 0.27-2.28 0.41-3.15 0.48-3.91 0.64-5.20
Rated input current A 1.17-9.91 0.59-4.56 0.69-5.66 0.92-7.53
Maximum input current A 13.5 5.8 7 9.5
Rated RCD type B mA 30 30 30 30
Rated Fuse aM / MCB type C A 20 10 10 16
Sound pressure level at 10m dB(A) 20.8-24.5 20.4-33.7 23.0-34.4 22.1-34.2
Recommended water flow rate m
3
/h 5.0-7.0 8.0-10.0 10.0-12.0 12.0-18.0
Pressure drop m/kPa 0.49/4.8 0.61/6.0 0.77/7.5 0.85-8.5
Pool water connections Inches 1½” or 50mm Female
GENERAL DATA
Net dimensions (w x d x h) mm 954x359x648 954x429x755 1084x429x948 1154x539x948
Packed dimensions (w x d x h) mm 1040x445x655 1040x445x770 1130x445x985 1200x5555x985
Net weight kg 52 68 93 120
HERMETIC SYSYEM
Refrigerant charge R32
kg 0.9 1.2 2.0 2.7
Minimum area requirement m2 6.9 12.3 34.0 62.0
NOTES: Heat pump performance parameters are subject to change wiout notice. Always refer to e
nameplate. Global warming potential (GWP) R32 - 675.
The data is subject to modification wiout prior warning.
