Product Specification
Model: DAP Audio COM-52
Power: AC 230V-50Hz (CE); Fuse 8A 250V
Dimensions: 19"x 185mm X 1HE (LxWxH)
Weight: 2,92 Kg
Receiver
Frequency stability: +/-0,005%
Image Interference rate: >80dB
S/N Ratio: >105dB
Sensitivity: -107dBM
T.H.D.: <0,5%
Output connectors: 2x3p. XLR balanced
2x 6,3mm jack unbalanced
1x 6,3mm jack mixed channel A & B
Audio output impedance: 600Ohm
Audio output level: -12dB
Frequency response: 15-20.000Hz
4 pre-programmable channels
Frequency range: 740.100 – 846 MHz in steps of 0.025 MHz
Power supply: 12-18V DC 1000mA
Microphone
Dynamic range: >110dB
Freq. Range: +/-48KHz
Spurious rejection: <-50dBc
RF-output: 10mW
Power consumption: 100mA
Battery's: 2x AA 1,5V
Material: Plastic body with metal head
Dimensions: ø32xø50x280mm (LxWxH)
Design and product specifications are subject to change without prior notice.
