DAPAudio D3502 - Description of the Device; Overview; Installation

5
Ordercode: D3502
PR-32 40W
Description of the device
Features
 Power consumption: 40W RMS
 Impedance: 16 Ω
 Woofer: 3,5”
 Tweeter: 12,6 mm Mylar Dome Tweeter
 Frequency range (-10 dB): 65 Hz - 20 kHz
 Connections: speaker cable connector IN
 Color: White
 IP rating: IP20
 Dimensions: 153 x 160 x 215 mm (LxWxH)
 Weight: 3,2 kg
Overview
Fig. 01
Installation
Remove all packing materials from the PR-32. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
