DAPAudio GIG-83CFX User Manual

20
GIG-83CFX
Order code: D2282
Technical Specifications
MODEL:
GIG-83CFX mixing console
Mono channels
Microphone input
XLR balanced
Frequency response
10Hz to 55KHz,+/-3dB
Distortion(THD+N)
<0.03% at +0dB ,22Hz~22KHz A-weighted
Gain range
0dB to 50dB
Max. Input
+15 dB
LOW CUT
100Hz
SNR
<-100dBr A-weighted
Phantom power
+48V with switch control
Line input
1/4' TRS balanced
Frequency response
10Hz to 55KHz,+/-3dB
Distortion(THD+N)
<0.03% at +0dB ,22Hz~22KHz A-weighted
Sensitivity range
+15dB~ -35dB
COMPRESSOR
GAIN:0~9dB
THRESHOLD:20dB---> ↓5dB
Stereo input channels
Mic input
XLR balanced
LOW CUT
100Hz
Line input
1/4' TRS or TRS/RCA un-balanced
Frequency response
10Hz to 55KHz,+/-3dB
Distortion(THD+N)
<0.03% at +0dB ,22Hz~22KHz A-weighted
Sensitivity range
-20dBu~ +20dBu
SNR
<-100dBr A-weighted
Channels EQ
mono channel
stereo channel
High
+/-15dB@12KHz
+/-15dB@12KHz
Mid
+/-15dB@2.5KHz
+/-15dB@2.5KHz
Low
+/-15dB@80Hz
+/-15dB@80Hz
2-TACK IN
TAPE IN
RCA jack
Frequency response
10Hz to 55KHz,+/-3dB
Distortion(THD+N)
<0.03% at +0dB ,22Hz~22KHz A-weighted
Gain range
OFF to 15dB
AUX RETURNS
Input
1/4' TRS un-balanced
Frequency response
10Hz to 55KHz,+/-3dB
Distortion(THD+N)
<0.03% at +0dB ,22Hz~22KHz A-weighted
GAIN range
OFF TO +15dB
SNR
<-100dBr A-weighted
Impedances
Microphone input
1.8KΩ
All other input
10KΩ or greater
Tape out
1K
All other out
120Ω
DSP section (options)
A/D and D/A converters
24bit
Type of effects
Echo ,Echo+Verb , Tremolo , Plate , Chorus ,Vocal
Rotary , Small Room , Flange + Verb , Large Hall
Controls
Mute switch & Foot-switching with LED indicator
100 position preset selector(10 preseter * 10 variation)
FOOT-SW
TIP:FX
SLEEVE:GND
Main mix section
Max. MAIN MIX output
+22dBu XLR balanced (+16dBu un-balanced)
