DAPAudio PR-82 - Description of the Device; Overview; Installation

5
Ordercode: D3510
PR-82 85W
Description of the device
Features
 Power consumption: 85W RMS
 Impedance: 16 Ω
 Woofer: 8”
 Tweeter: 25,2 mm Textile Dome Tweeter
 Frequency range (-10 dB): 35 Hz - 20 kHz
 Connections: speaker cable connector IN
 Color: White
 IP rating: IP20
 Dimensions: 255 x 270 x 355 mm (LxWxH)
 Weight: 11,2 kg
Overview
Fig. 01
Installation
Remove all packing materials from the PR-82. Check that all foam and plastic padding is removed.
Connect all cables.
Always disconnect from electric mains power supply before cleaning or servicing.
Damages caused by non-observance are not subject to warranty.
