DAPAudio Qi-4200 - Product Specifications; Technical Specifications Summary

12
Ordercode: D4530 / D4531 / D4532
Qi-4200 / 4400 / 4600
Product Specifications
Rated power / model
Qi-4200
Qi-4400
Qi-4600
1kHz (HIA) with 1%THD
4Ω stereo (per channel):
4 x 200W
4 x 400W
4 x 600W
8Ω stereo (per channel):
4 x 120W
4 x 250W
4 x 360W
8Ω bridge mono:
2 x 400W
2 x 800W
2 x 1200W
Power supply:
120-230VAC, 60/50Hz
Power consumption (2 x 4Ω):
1100W
Max Input Voltage:
+20dBu
Performance
Frequency Response (at 1 Watt):
+/-2dB
Input Sensitivity for full rated power
at 8Ω:
0.65V
0.7V
0.775V
Input impedance:
20kΩ balanced, 10kΩ unbalanced
S/N:
>90dB
VR residual sound:
>85dB
AMP efficiency:
>93%
Front panel controls:
AC power switch, CH1 - CH4 gain control
Ground-lift:
No
Signal to Noise Ratio:
-96.5dB Flat, -100dB(A)
Amplifier protection:
Short circuit thermal, turn-on and –off muting, DC fault
output and RF protection
Control
Output modes
Stereo / mono / bridge
LED indicators:
Power ON - Blue
Protect – Orange
Signal – Green
Limit – Red
Inputs:
4 x 3-pin XLR
Outputs:
4 x Speakon
AMP class:
Class D
Construction
Cooling system:
Variable speed cooling fan
Dimensions:
483 x 390 x 44 mm (LxWxH)
19 inch x 1HE (LxH)
Weight:
6.4 kg
Design and product specifications are subject to change without prior notice.
