DAS MAX Series - Tent Assembly Step 1; Assembly for Even Side Length Tents; Assembly for Uneven Side Length Tents

20

STEP 1
The tent should be put on a flat surface.
Tent installation instructions
Tent 6m type sp38
Extention tube of 1m (nr.3) should be
placed in the third section. 
F o r t e n t s w i t h e v e n l e n g t h o f t h e s i d e e.g.: 8m, 10m, 12m, 20m, 30m…

Unfold the itmes as below. Connect all pipes Φ38 with connectors by screw M6x50.
