Data Aire DARC 11 User Manual

12 • Air Cooled Condenser User Manual
Note: Field connections at the indoor evaporator section and remote condenser will not
necessarily be the same as the eld pipe size required. These could vary signicantly.
2.5 Condenser Connection Sizes
CONDENSER CONNECTION SIZES – Single Circuit
Standard
Fans
Discharge
(Hot Gas) Line
Liquid
Line EC Fans
Discharge
(Hot Gas) Line
Liquid
Line
DARC 03 1/2” 1/2” GHRC 011 1/2” 1/2”
DARC 05 1/2” 1/2” GHRC 018 1/2” 1/2”
DARC 07 1-1/8” 7/8” GHRC 025 1-1/8” 7/8”
DARC 09 1-1/8” 7/8” GHRC 032 1-1/8” 7/8”
DARC 11 1-1/8” 7/8” GHRC 039 1-1/8” 7/8”
DARC 15 1-1/8” 7/8” GHRC 053 1-1/8” 7/8”
DARC 17 1-3/8” 7/8” GHRC 060 1-3/8” 7/8”
DARC 21 1-3/8” 7/8” GHRC 074 1-3/8” 7/8”
CONDENSER CONNECTION SIZES – Dual Circuit
Standard Fans
Discharge
(Hot Gas) Line
Liquid
Line EC Fan(s)
Discharge
(Hot Gas) Line
Liquid
Line
DARC 07 1-1/8” 7/8” GHRC 025 1-1/8” 7/8”
DARC 09 1-1/8” 7/8” GHRC 032 1-1/8” 7/8”
DARC 11 1-1/8” 7/8” GHRC 039 1-1/8” 7/8”
DARC 15 1-1/8” 7/8” GHRC 053 1-1/8” 7/8”
DARC 17 1-3/8” 7/8” GHRC 060 1-3/8” 7/8”
DARC 21 1-3/8” 7/8” GHRC 074 1-3/8” 7/8”
DARC 24 1-3/8” 7/8” GHRC 084 1-3/8” 7/8”
DARC 28 1-3/8” 7/8” GHRC 099 1-3/8” 7/8”
DARC 30 1-3/8” 7/8” GHRC 106 1-3/8” 7/8”
DARC 37 1-5/8” 1-1/8” GHRC 130 1-5/8” 1-1/8”
DARC 40 1-5/8” 1-1/8” GHRC 141 1-5/8” 1-1/8”
DARC 44 1-5/8” 1-1/8” GHRC 155 1-5/8” 1-1/8”
DARC 50 1-5/8” 1-1/8” GHRC 176 1-5/8” 1-1/8”
DARC 57 (DW)
2
1-3/8” 7/8” GHRC 201 1-3/8” 7/8”
DARC 61 (DW)
2
1-3/8” 7/8” GHRC 215 1-3/8” 7/8”
DARC 75 (DW)
2
1-5/8” 1-1/8” GHRC 264 1-5/8” 1-1/8”
DARC 80 (DW)
2
1-5/8” 1-1/8” GHRC 281 1-5/8” 1-1/8”
DARC 88 (DW)
2
1-5/8” 1-1/8” GHRC 310 1-5/8” 1-1/8”
DARC 100 (DW)
2
1-5/8” 1-1/8” GHRC 352 1-5/8” 1-1/8”
2 DW - double wide condenser
