Data East Batman - Playfield Major Assemblies; Playfield Assembly List

Playfield
-
Major Assemblles
Item
CXÌ CO IO CO !< CÓ O)
10
.
11
15
.
16
.
17
.
Description
Up Down Target
Pop Bumper
Sling Shot
Super VUK
Bat Cave
3 Bank Standup Target
Super VUK
Flipper Assy Rlght
Flipper Assy Left
Ball Trough eject
Outhole Klcker
Joker Chute Assy.
Up Down Chute Assy.
Plastlc Ramp Assy.
Joker Ramp Assy.
Ball Trough Assy.
Ball Diverter
Bottom Arch
Turbo Kicker
Pari Number
500-5386-00-11
500-5227-00
500-5226-00
500-5116-04
545-5281-00
500-5384-03
500-5116-03
500-5177-71
500-5177-72
500-5012-01
500-5082-00
535-5929-00
515-5400-00
500-5385-00-11
500-5388-00-11
500-5044-00
535-6116-00
545-5170-00
500-5406-00
Individuai part breakdowns for most of
these assemblies can be found
on pages 35 through 41 and 63 & 64.
