Data East Batman - Backbox Parts Illustration; Backbox Component List; Rubber Parts Illustration; Rubber Component List

BACKBOX PARTS ILLUSTRATION
Item
1
•r
-
CM
co in co
RUBBER PARTS
ILLUSTRATION
Item Description
“ IQTimppro >
CO 00 ^1
10
CM CO
Description Part No.
CPU Board Assy.(Non-Reflx) 520-5003-031
Sound Board Assy 520-5050-001
Capacitor 2C1 125-5000-00
Bridge Rectifiers 112-5000-00
Power Supply Bd. Assy 520-5047-00
PPB Board 520-5021-04
Dot Matrix Display Bd 520-5042-001
Display Rlbbon Cable* 036-5000-24-10
Speaker Housing 500-5416-00-10
Speakers (2) 031-5004-00
Speaker Grill (2) 830-5604-00
Back Box Glass* 830-5211-00
Roto-Lock Top* 355-5006-02
* Not Shown
t When ordering PC Boards wlth ROMs
please specify game name
Pari#
Rubber Post -Long(8) 545-5260-00
Flipper (2) 545-5277-00
3
/i6"(2) 545-5025-01
5
/i6" (8) 545-5025-02
1/2" (3) 545-5025-07
2 72" (2) 545-5025-09
2
3
/4"(2) 545-5025-20
Shooter Tip 545-5027-00
Rubber Post -Short (2) 545-5151-00
32
Parts Identification
