Data East Batman - Playfield Parts; Detailed Playfield Component List

Playfleld Parts
No. Description
a
10.
11.
12.
13.
14.
15.
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
*29.
*30.
31.
32.
33.
34.
*35.
*36.
37.
*38.
*39.
*40.
41.
42.
43.
44.
45.
#6X1/2 HexTyp.
Plastic Spacer (1)
Plastic Spacer (1)
Plastic Spacer (1)
1/2 Hex Spacer
1 3/4 Plastic Spacer
Retaining Ring
Wire Gate and Switch
Batmoblle
Lower Left Return
Lower Right Return
Bumper Post Mach
Post Wood Screw
Mach Post
Metal Standoff
Mach Post Screw
Diverter Shaft
Wire Form 1"
Wire Form
Rebound Hinge
Ball Deflector
Ramp Side Piate
Wire Form
Ramp Piate
Joker Ramp Brkt.
Museum Brkt.
Joker Ramp Piate
Ball Diverter
Llght Cover Red
Light Cover Green
Bumper Cap
Flugenheim Museum
Small Plastic Post
Light Hood Single
Coìnage Card
Instruction Card
Decal Sheet
Playfield Mylar
Screened Playfield
Screened Plastics
SB Mini Hat Mars Amber
SB Mini Mars Amber
SB Mini Mars
SB Mini Mars Clear
Scoop
Pari Number
234-5001-02
254-5000-02
254-5000-06
254-5000-07
254-5008-03
254-5008-10
270-5002-00
500-5314-00-11
500-5328-00-11
517-0111-07-11
517-0111-08-11
530-5007-00
530-5010-01
530-5012-02
530-5035-01
530-5012-02
530-5173-07
535-5300-08
535-5300-12
535-5372-00
535-5380-01
535-5442-00
535-5603-00
535-5884-00
535-5890-00
535-5894-01
535-6052-00
535-6116-00
545-5014-02
545-5014-04
545-5225-03
545-5280-00
550-5034-03
550-5035-03
755-5008-02
755-5011-00
820-5060-XX
820-5818-00
830-5111-00
830-5415-XX
550-5032-03
550-5031-03
550-5031-07
550-5031-01
535-6030-00
Note:
See page 25 for switch part numbers
*
Indicates not shown
Parts Identification 33
