Temperature & Process Measurement Indicators Setup Guide
20-5110 Issue G 3
Installation
To install your instrument, you will need to carry out the following steps:
Apply the engineering units label to the right-hand side of the display
panel. A sheet of labels covering the most commonly used
engineering units is supplied with all units. If the unit you require is
not on the sheet, a blank label is provided on which you can use
LETRASET™.
Install the instrument into a panel.
Make connections to the instrument.
PLEASE NOTE:
Ensure that the power to the instrument is switched off before
carrying out any installation or maintenance work.
It is recommended that all connections to the terminals are made using
ferrules to afford greater reliability and to prevent short circuits
between adjacent terminals.
Avoid installing the instrument close to switch gear, contactors or
motor starters.
Do not place signal and power supply wiring in the same loom.
Use screened cables or wires for all signal/sensor leads with screen
earthed at one point only.
Panel Mounting
The instrument is supplied with an installation kit consisting of a mounting
clamp, a panel sealing gasket and terminal connectors.
Ensure that there is sufficient space behind the instrument panel - the
instrument requires a depth of 100mm (110mm when any options are
fitted) plus enough space to allow safe routing of cables.
To install the instrument:
1. Make panel cut-out with the dimensions as shown overleaf. Panel
thickness from 1.5mm to 9.5mm can be accommodated.
