Data Translation DT300 Series User Manual

Specifications
137
Power, Physical, and Environmental Specifications
Table 29 lists the power, physical, and environmental specifications for the DT300 Series
board.
Table 29: Power, Physical, and Environmental Specifications
Feature Specifications
Power
+5 V (±0.25 V):
− 5 V:
+12 V:
−12 V:
+ 5 V Power Out (J1-1):
1.2 A nominal
not used
55 mA maximum; 48 mA nominal
50 mA maximum; 38 mA nominal
1 A maximum (with resettable fuse)
Physical
Dimensions:
Weight:
Length: 6.875 inches (174.63 mm)
Width: 4.2 inches (106.68 mm)
4.38 ounces (124 grams)
Environmental
Operating temperature range:
Storage temperature range:
Relative humidity:
0° C to 70° C
–25° C to 85° C
To 95%, noncondensing
