Screw Terminal Assignments for Connector J1 on the
STP300
Table 34 lists the screw terminal assignments for connector J1 on the STP300 screw terminal
panel.
Table 34: Pin Assignments for Connector J1 on the STP300
TB J1 Pin Description TB J1 Pin Description
1 68 Analog Input 0 2 67 Analog Input 8/0 Return
3 34 Analog Input 1 4 33 Analog Input 9/1 Return
5 66 Analog Input 2 6 65 Analog Input10/2 Return
7 32 Analog Input 3 8 31 Analog Input 11/3 Return
9 64 Analog Input 4 10 63 Analog Input 12/4 Return
11 30 Analog Input 5 12 29 Analog Input 13/5 Return
13 62 Analog Input 6 14 61 Analog Input 14/6 Return
15 28 Analog Input 7 16 27 Analog Input 15/7 Return
17 26 Amp Low 18 25 Analog Ground
19 58 DAC0 Output 20 57 DAC0 Return
21 60 DAC0 Reference In and Out 22 23 DAC1 Return
23 24 DAC1 Output 24 59 DAC1 Reference In and Out
25 42 Digital Ground 26 41 User Clock Input 0
27 40 User Counter Output 0 28 39 External Gate 0
29 8 Digital Ground 30 7 User Clock Input 1
31 6 User Counter Output 1 32 5 External Gate 1
33 8 Digital Ground 34 36 User Clock Input 2
35 37 User Counter Output 2 36 38 External Gate 2
37 42 Digital Ground 38 2 User Clock Input 3
39 3 User Counter Output 3 40 4 External Gate 3
41 1 +5 V Output @ 1 A 42 35 Power Ground
43 55 Digital Ground 44 55 Digital Ground
45 55 Digital Ground 46 56 External A/D Trigger
47 21 Digital Ground 48 22 External A/D Sample Clock
Input
49 50 Digital I/O Port A, Line 0 50 16 Digital I/O Port A, Line 1
51 49 Digital I/O Port A, Line 2 52 15 Digital I/O Port A, Line 3
53 48 Digital I/O Port A, Line 4 54 14 Digital I/O Port A, Line 5
