Principles of Operation

Similarly, assume that you are using a DT322 board with a bipolar output range of ±10 V. The

minus full-scale value is −10 V. If you want to output a voltage of 4.7 V, determine the code

value as follows:

LSB = 20

= 0.000305 V

65536

Code = 4.7 V

– (–10 V)

0.000305 V

Code = 48196 = BC44h
