Chapter 7
102
Counter/Timers
Table 20: DT3000 Series Counter/Timer Options
DT3000 Series A/D D/A DIN DOUT C/T QUAD
Cascading Support
SupportsCascading
Event Count Mode Support
SupportsCount Ye s
Generate Rate Mode Support
SupportsRateGenerate Ye s
One-Shot Mode Support
SupportsOneShot Ye s
a
Repetitive One-Shot Mode Support
SupportsOneShotRepeat Ye s
b
Up/Down Counting Mode Support
SupportsUpDown
Edge-to-Edge Measurement Mode Support
SupportsMeasure
Continuous Edge-to-Edge Measurement
Mode Support
SupportsContinuousMeasure
High to Low Output Pulse Support
SupportsHighToLowPulse Ye s
Low to High Output Pulse Support
SupportsLowToHighPulse
Variable Pulse Width Support
SupportsVariablePulseWidth Ye s
c,d
None (internal) Gate Type Support
SupportsGateNone Yes
a
High Level Gate Type Support
SupportsGateHighLevel Ye s
e
Low Level Gate Type Support
SupportsGateLowLevel Ye s
e
High Edge Gate Type Support
SupportsGateHighEdge Ye s
f
Low Edge Gate Type Support
SupportsGateLowEdge Ye s
f
Level Change Gate Type Support
SupportsGateLevel
Clock-Falling Edge Type
SupportsClockFalling
Clock-Rising Edge Type
SupportsClockRising
Gate-Falling Edge Type
SupportsGateFalling
