2. Introduction
HD IP Streaming Server allows users to stream CVBS / Component / HDMI source over Network to
IP Box or computers within Network.
DT-HDIPSSL Manual
2.1 Packing Content
Please check whether the following items are present in the package. If any items is missed or
damaged, please call your DataTronix.
1 - DT-HDIPSSL HPD IP Streamer
1 - Power Adapter
1 - User Manual
2.2 Description of controls and components
Please check whether the following items are present in the package. If any items is missed or
damaged, please call your DataTronix.
1 - DT-HDIPSSL HD IP Streamer
1 - Power Adapter
1 - User Manual
1 LCD Display
Confi guration and system status
2 Home Button
Return to previous or Start menu
3 Left & Right Buttons
Move Right / Left between menu / characters
4 Up & Down Button
Increase / Decrease the fi eld value, Increase / Decrease value of the password
5 Enter Button
Select parameter / menu
6 IP Output
RJ-45,GbE / 10M, 100M, 1000M
7 Ethernet Port
RJ-45,GbE / Chrome
8 Audio/Video Input *4
HDMI/ Component YPrPb(RCA) / Composite CVBS(RCA)
9 DC Input
12V DC
1
2
33
4
4
5
6
7
8
9
Front and Rear Panels
