VGA and Audio Cat-X AV Extender
5 / 16
3. System Devices & Function
One-Port Transmitter AVE-301T:
(1) Built in one set of AV inputs
(2) Built in one set of AV outputs to monitor the AV signal broadcasted
(3) Built in one RJ-45 port for system output which can be connected by
Cat5/5e/6 cable and send signal to System Receiver
(4) Take the power from USB or power adaptor
4 / 8 / 16-Port Transmitter AVE-304T, AVE-308T, AVE-316T:
(1) Built in one set of AV inputs
(2) Built in one set of AV output to monitor the AV signal broadcasted
(3) Built in 4/8/16 R-J45 ports for system output which can be connected
by Cat5/5e/6 cable and send signal to 4/8/16 sets of System Receiver
or Transceiver
4/8-Port Transceiver AVE-304TR, AVE-308TR:
(4) Built in one Remote system input (RJ45) which can receive the AV
signal and with video and focus control to adjust the video quality
(5) Built in one set of AV output to monitor the AV signal broadcasted
(6) Built in 4/8 RJ-45 ports for system output which can be connected by
Cat5/5e/6 cable and send signal to 4/8 sets of System Receiver or
Transceiver
Receiver AVE-301R:
(1) Receive AV signal through RJ45 port, and with video and focus control,
you can adjust the video quality, the maximum supported extended
VGA resolution and distance up to 2048x1536@300m
(2) Built in one set of AV outputs (VGA + Audio) to display the AV signal
broadcasted
