4. Panel Descriptions
 AVE-301T Single-Port AV Transmitter
Power Indicator Power Jack
VGA + Audio Output VGA + Audio + USB Power Input
RJ-45 AV Output H & V Sync Activity
Magnetic Pad
 AVE-301R Single-Port AV Receiver
Power Indicator Power Jack
VGA + Audio Output Video Control
RJ-45 AV Input H & V Sync Activity
Magnetic Pad
