DKG-307 User Manual V-37 (01.03.2012)
- 47 -
The parameters below define the functions of relay outputs. The unit has 6 relay outputs. The
fixed function relays are Fuel, Start, Mains Contactor and Generator Contactor. RELAY-1 and RELAY-
2 have programmable functions, selected from a list.
The relays may be extended up to 22 using Relay Extension Modules.. Other relays are in
the optional Extension Modules.
Program Group: Relay Definitions (password level-2)
PGM
Parameter Definition
Unit
Fac.Set
Description
P_226
Relay 01 Definition
3
RELAY-1 function selected from list
P_227
Relay 02 Definition
1
RELAY-2 function selected from list
P_228
Relay 03 Definition
0
RELAY-3 function (expansion module) selected from
list
P_229
Relay 04 Definition
2
RELAY-4 function (expansion module-1) selected
from list
P_230
Relay 05 Definition
4
RELAY-5 function (expansion module-1) selected
from list
P_231
Relay 06 Definition
5
RELAY-6 function (expansion module-1) selected
from list
P_232
Relay 07 Definition
0
RELAY-7 function (expansion module-1) selected
from list
P_233
Relay 08 Definition
2
RELAY-8 function (expansion module-1) selected
from list
P_234
Relay 09 Definition
4
RELAY-9 function (expansion module-1) selected
from list
P_235
Relay 10 Definition
5
RELAY-10 function (expansion module-1) selected
from list
P_236
Relay 11 Definition
0
RELAY-11 function (expansion module-2) selected
from list
P_237
Relay 12 Definition
2
RELAY-12 function (expansion module-2) selected
from list
P_238
Relay 13 Definition
4
RELAY-13 function (expansion module-2) selected
from list
P_239
Relay 14 Definition
5
RELAY-14 function (expansion module-2) selected
from list
P_240
Relay 15 Definition
0
RELAY-15 function (expansion module-2) selected
from list
P_241
Relay 16 Definition
2
RELAY-16 function (expansion module-2) selected
from list
P_242
Relay 17 Definition
4
RELAY-17 function (expansion module-2) selected
from list
P_243
Relay 18 Definition
5
RELAY-18 function (expansion module-2) selected
from list
