DKG-307 User Manual V-37 (01.03.2012)
- 7 -
The unit has 12 LEDs, divided in 3 groups:
-Group_1: Operating mode: This group indicates the genset function.
-Group_2: Mimic diagram: This group indicates the current status of the mains and genset
voltages and contactors.
-Group_3: Warnings and alarms: This group indicates the existence of abnormal conditions
encountered during operation.
Function
Color
Description
MAINS ON
Green
The LED will turn on when all 3 mains phase voltages
are within the limits.
MAINS OFF
Red
The LED will turn on when at least one of the mains
phase voltages is outside limits.
LOAD MAINS
Green
It turns on when the mains contactor is activated.
LOAD GENERATOR
Yellow
It turns on when the generator contactor is activated.
GENERATOR
Yellow
The LED will flash when the engine is running. It will
turn on steadily when all 3 generator phase voltages
are within the programmed limits.
TEST
Yellow
It turns on when the related operation mode is
selected. One of these LEDs is always on and
indicates which operation mode is selected.
If the operation of the genset is disabled by the
weekly operation schedule, then the AUTO led will
flash.
RUN
Yellow
STOP
Yellow
AUTO
Green
WARNINGS & ALARMS
Red
If a fault condition resulting to the engine shutdown or
loaddump condition has occurred, the related alarm
led turns on steadily. If a warning condition occurs,
this led will flash. Alarms work on a first occurring
basis. The occurrence of a fault will disable other
faults of lower or equal priority.
SERVICE REQUEST
Red
Engine periodic maintenance request indicator. It
turns on when the preset engine hours or time
duration after previous service has elapsed.
3.1 Led Displays
3. DISPLAYS
