Datalogic Memor Quick Guide

WARNING
Do not apply voltages to the battery pack
contacts.
Do not pierce the battery pack with nails, strike
it with a hammer, step on it or otherwise
subject it to strong impacts or shocks.
Do not disassemble or modify (i.e. bend, crush
or deform) the battery pack. The battery pack
contains safety and protection devices, which,
if damaged, may cause the battery pack to
generate heat, explode or ignite.
In case of leakage of liquid from the battery,
avoid contact with liquid the skin or eyes. If the
contact occurs, immediately wash the affected
area with water and consult a doctor.
Do not solder directly onto the battery pack.
Do not expose the battery pack to liquids.
Avoid any knocks or excessive vibrations. If
the device or the battery is dropped, especially
on a hard surface, you should take it to the
nea
rest Authorised Repair Centre for
inspection before continuing to use it.
Do not remove or damage the battery pack’s
label.
Do not use the battery pack if it is damaged in
any part.
Battery pack usage by children should be
supervised.
Collect and recycle waste batteries separately
from the device in comply with European
Directive 2006/66/EC, 2002/95/EC,
2002/96/EC and subsequent modifications, US
and China regulatory and others laws and
regulations about environment.
BATTERY CHARGING STATUS LED DESCRIPTION
LED Status
Power Green It is constant when the battery
charger is powered
Charger Off Empty slot
Red Constant Charging
Green Constant Charge completed
Orange Constant Failure
TECHNICAL FEATURES
ELECTRICAL
Power supply
5 V*
Max consumption
3 A
Charge time 1100 mAh Battery: max. 4 hours
2000 mAh Battery: max. 6 hours
1430 mAh Li-Ion Battery: max. 5 hours
2300 mAh Li-Ion Battery: max. 7 hours
PHYSICAL
Dimensions 21.5 x 8.5 x 7 cm
Weight (without batteries) 450 g
LEDs
4 Charger Status LEDs
1 Power on LED
ENVIRONMENTAL
Working temperature 0° to +50 °C**
Storage temperature -20° to +70 °C
Humidity 80% without condensation
* Recommended power supply: 94ACC1324 PG5-30P35
AC/DC POWER SUPPLY EU/USA PLUG
** All the batteries must be charged at a temperature
ranging from 0° to +35 °C.
Even if the storage temperature range is wider, In
order to achieve the longest battery life, store the
spare batteries between 20 to 30 ºC (68 to 86 ºF).
NOTE
COMPLIANCE
FCC Compliance
 This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) This
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
 This device has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiated radio frequency energy and, if not installed
and used in accordance with the instructions, may cause
harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or
more of the following measures:
− Reorient or relocate the receiving antenna.
− Increase the separation between the equipment and
receiver.
− Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
− Consult the dealer or an experienced radio/TV
technician for help.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user‘s authority to
operate the equipment.
Industry Canada (ICES-003) Compliance
This Class B digital apparatus complies with Canadian ICES-
003.
Cet appareil numérique de la classe B est conforme à la norme
NMB-003 du Canada.
©2008-2017 Datalogic S.p.A. and/or its affiliates. All rights reserved.
Datalogic and the Datalogic logo are registered trademarks of Datalogic
S.p.A. in many countries, including the U.S. and the E.U. Memor is a
trademark of Datalogic S.p.A. and/or its affiliates. All other brand and
product names may be trademarks of their respective owners.
www.datalogic.com

Datalogic Memor Specifications

General

Scan speed	104 sec/page
Wavelength	630 nm
Sensor type	Laser
Decoding standards	UPC A, UPC E, EAN 8, EAN 13, Code 39, Code 39 Full ASCII, Code 32, Interleaved 2 of 5, Industrial 2 of 5, Matrix 2 of 5, Code 128, EAN 128, Codabar, MSI, Plessey, Code 93, Code 11, GS1 Databar.
Product color	Black
Internal memory	256 MB
Built-in processor	PXA310
Display resolution	240 x 320 pixels
Processor frequency	624 MHz
Bluetooth	Yes
Standard interfaces	USB, RS-232
Battery type	Li-polymer/Li-ion
Input voltage	5 V
Power consumption	1100 mA
Safety	Class 2
Display	Reflective TFT 64K
Dimensions (WxDxH)	152 x 55 x 40 mm
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C

Weight and Dimensions

Weight	230 g
