DATAMAN S4 MANUAL
74 INTEL<$IFile Formats;Intel> Format.
<$IINTEL HEX File Format>An Intel format file
can be examined with
a text editor and printed. Each record is a single
line of ASCII characters,
expressing bytes as Hexadecimal pairs, terminated
with Carriage return
and Linefeed.(0D,0A).<R>
The transmission is terminated by ASCII End-of-
File (1A).
Extended Address Record.
@LIST 1 = Position
@LIST 2 = Remarks
@LIST 1 = 1
@LIST 2 = ":" ASCII Colon delimiter
@LIST 1 = 2-3
@LIST 2 = "02" Byte count
@LIST 1 = 4-7
@LIST 2 = "0000" Address not used
@LIST 1 = 8,9
@LIST 2 = "02" Record type
@LIST 1 = 10-13
@LIST 2 = Upper Segment Base Address.<R>
Top 16 bits of 20 bit address.<R>
Most significant byte first.<R>
2 bytes as 4 HEX characters.<R>
USBA defaults to 0 if not sent.
@LIST 1 = 14,15
@LIST 2 = Checksum complement of all bytes
except colon, linefeed
and return.<R>
1 byte as 2 hex characters.<R>
This makes the line add up to zero.
@LIST 1 = 16,17
@LIST 2 = Carriage return and line feed
