DATAMAN S4 MANUAL
INTEL<$IFile Formats;Intel> Format. 75
Data Record.
@LIST 1 = Position
@LIST 2 = Remarks
@LIST 1 = 1
@LIST 2 = ":" ASCII Colon delimiter
@LIST 1 = 2-3
@LIST 2 = Data byte count in HEX, max
"20"<R>
(32 bytes or 64 ASCII characters)
@LIST 1 = 4-7
@LIST 2 = Lower 16 bits of 20 bit address<R>
Most significant byte first.<R>
2 bytes or 4 HEX characters.<R>
Must be added to USBA to form<R>
20 bit address.
@LIST 1 = 8,9
@LIST 2 = "01" Data Record
@LIST 1 = 10-N
@LIST 2 = Data bytes in hexadecimal.<R>
Each byte is two HEX characters
@LIST 1 = N+1,2
@LIST 2 = Checksum complement of all bytes
except colon, linefeed
and return.<R>
This makes the line add up to zero.
@LIST 1 = N+3,4
@LIST 2 = Carriage return and line feed
@LIST 2 =
End of File Record.
@LIST 1 = Position
@LIST 2 = Remarks
@LIST 1 = 1
@LIST 2 = ":" ASCII Colon delimiter
