Click on the display wall representation to open the display wall tab (2).
When opened, the display wall tab shows a live representation of the physical wall
and the sources available to display on it. To place a source on the video wall, simply
click on the required source in the Sources Tab and drag it onto a preferred position
on the display wall representation.
The application help le is accessed using the question mark icon (?) located on the
top right of the WallControl 10 Client. The help le contains information explaining
how multiple sources can be selected, how to use and create templates, how to
save, recall and share layout les and manage walls.
Sources
Display Wall
Tab
Display Wall
Representation
The WallControl 10 - Security Administration Client (Only Available with
WallControl 10 Pro)
Start | All Programs | WallControl 10 - Security Administration Client
Page 11
A WallControl 10-Pro serial dongle must be inserted into a vacant USB port. If the
dongle is removed or swapped, the Security Client will not open and an error
message is displayed, therefore it is important the dongle is not removed.
If you have purchased WallControl 10 Pro, the licence dongle can be located in the
accessories box.
