Datapath VisionSC-DP2 User Manual

Board Format PCI-Express x8 plug-in card, 110mm x 177mm (incl heat sync)
Connectors (main board) 2 x locking DisplayPort 1.2
Maximum Capture
Resolution
616MPixel/second capture bandwidth per channel providing 2
x 3840x2160 at 60Hz. Maximum capture surface of 8k x 8k at
lower frame rates*.
Frame Buer 768MB
Input Mode Detection Supports SMPTE - 352 Payload Identiers
Pixel Transfer Formats Polyphase FIR scaling engine (3x3) for hardware downscaling
and upscaling
Colour space conversion allows captured data to be
transferred in any format:
RGB:5-5-5, 5-6-5 or 8-8-8 (24bit/32bit)
YUV: 4:2:2, 4:2:0
MONO: 8bit
Audio Capture Embedded audio capture
Operating System Support Windows XP, Windows Server 2003, Windows Vista, Windows
Server 2008, Windows 7, Windows 8/8.1 and Linux
Power Requirements Max current at 12V – 1.0A
Max power ≈ 12W
Operating Temperature 0 to 35 ºC ( 32 to 96ºF)
Storage Temperature -20 to 70 ºC ( -4 to 158ºF)
Relative Humidity 5% to 90% non-condensing
Warranty 3 years
7
Specification
We are continuously developing the technology used within our product ranges delivering outstanding
innovative solutions, therefore the specication may change from time to time.
* 8K x 8K at lower frame rates supported based on preliminary testing. Further testing to be scheduled on
availability of 8k sources.
