Datapath VisionSC-SDI4 User Manual

Hardware Overview
Four Channel 3G-SDI Video Capture Card
• Four independent 3G SDI capture channels
• Four channels of 1920 x 1080p 60fps capture
• Eight lane PCIe Gen.3 interface,
• Frame buer memory - 768 MB
• Single PCIe endpoint, allowing for more cards & captures to be placed within a single system.
Datapath Vision Performance Driver
Multiple cards per system, 16 streams per card
Frame sync and time stamping
Automatic signal detection
Direct Show interface
Datapath RGBEasy API
Models
VisionSC-SDI4 - 3G-SDI Video Capture Card
4
Fig. 2
Fig. 1

Datapath VisionSC-SDI4 Specifications

General

Brand	Datapath
Model	VisionSC-SDI4
Category	PCI Card
Language	English
