Datapath VisionSC-SDI4 User Manual

Board Format PCI-Express x8 plug-in card, 110mm x 177mm (incl heat sync)
Connectors (main board) 4 BNC Connectors
Maximum Capture
Resolution
2.97Gbps capture bandwidth per channel.
Provides => 4 * 1920 x 1080p @ 60Hz.
Frame Buer 768MB
Input Mode Detection Supports SMPTE - 352 Payload Identiers
Sample Formats RGB: 4-4-4 (+A)
YUV: 4:2:2 (+A), 4:4:4 (+A)
SMPTE Standards ST-259, ST-272, ST-274, ST-291, ST-292, ST-293, ST-296,
ST-299, ST-352, ST-424, ST-425, ST-2048
Update Rate User dened. Captured frame rate will match the source
providing max data rate (2.9GB/s per channel) is not exceeded.
Multi-buered to eliminate tearing artefacts.
Video Modes 480i, 576i 720p, 1080i, 1080p,1080psF, 2048x1080p,
2048x1080psF
Supported Frame Rates 23.98Hz, 24Hz, 25Hz, 29.97Hz, 30Hz, 50Hz, 59.94Hz & 60Hz
Audio Capture Embedded audio capture
Operating System Support Windows OS ® up to Win 8/8.1
Power Requirements Max current at +3.3 - 0.45A.
Max current at +12V - 0.85A
Max power ≈ 18W
Operating Temperature 0 to 35 ºC ( 32 to 96ºF)
Storage Temperature -20 to 70 ºC ( -4 to 158ºF)
Relative Humidity 5% to 90% non-condensing
Warranty 3 years
7
Specification
We are continuously developing the technology used within our product ranges delivering outstanding
innovative solutions, therefore the specication may change from time to time.
