Datapath VSN450 - Step 5 Connect Control Screen (Optional) and Monitors

Page 4
STEP 5 CONNECT CONTROL SCREEN (OPTIONAL)
AND MONITORS
3 x 2 Video Wall
4 x 2 Video Wall
Control Screen
Monitor 2
Monitor 3
Monitor 4
Monitor 5
Monitor 7
Monitor 6
Monitor 8
Monitor 1
Connect graphic outputs to
monitors using DisplayPort cables,
(not supplied).

factory. Connect a control screen to the SBC as shown.
