STEP 5 CONNECTING A CONTROL SCREEN
The printed input/output diagram shipped with your VSN wall controller shows
where the video inputs are located and the types of input connectors installed in
your system.
Connect the input sources to the relevant video input connectors, cables may be
supplied for some inputs, see content list for details.
systems internal graphics device prior to leaving the factory. Connect the control
screen to the motherboard graphics output connector on the rear of the VSN wall
controller. A control screen is initially required to set up the system including the
operating system (Windows 10).
Control Screen
VGA or DVI
Page 5
To Next Page
