Dataprobe iBoot-G2 Quick Start Guide

Mounting Options
iBoot-G2+ is suitable for desktop or shelf mounting. A mounting kit for
wall and DIN rail mounting is available. Order part:
1920033 Mounting Kit for iBoot-G2 Series

Installing the Wall Mounting Kit
DIN Rail Mounting
1. Remove all cables
from the unit
1. Install the Wall
Mounting Kit as
shown.
2. Remove the four
mounting screws
from the underside
of the unit.
Do not
disassemble the
unit.
2. Install the DIN rail
clips using the four
screws provided.
3. Install the wall
mounting ears to
the unit using the
screws removed in
Step 2
3. Ready for DIN rail
mounting.
4. The unit is ready
for wall mounting.
Use M3 or #4
screws (not
included) for
attachment to
suitable surface.
1920033 Mounting Kit
iBoot G2 Series
