2-8 HH7700-MSOP
2: Radio Basics
Attaching the Belt Clip
1. Using your thumb, press
the clip’s spring latch
towards the top of the
clip. Slide the latch down
into the groves of the
radio and release your
thumb.
2. Place the screw on top of
the phillips screwdriver
and keep it in place while
passing the screwdriver
through the opening of
the clip.
3. Tighten the screw to the
battery.
Removing the Belt Clip
1. Using a phillips screwdriver,
loosen the screw positioned
through the opening in the
clip and remove it.
2. Using your forefinger, press
the clip toward the battery
and slide the clip up and off.
