CROSSLINE LASER LEVEL
TROUBLESHOOTING
ISSUE POSSIBLE CAUSE AND SOLUTIONS
Laser does not turn on
Check batteries. Make sure batteries are installed according to the
correct polarity.
The batteries may be depleted. Make sure the batteries are in proper
working condition. If in doubt, try installing new batteries.
If the laser has been stored in extremely hot temperatures, allow it to
cool.
Laser does not level Instrument may be outside it’s levelling range. Position the
instrument, tripod or the base surface.
Instrument may have impact damage. Contact service centre for
repair and calibration.
PRODUCT LABELS
DT3X360R
DT3X360G
CAUTION: LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER PRODUCT
