59
Waveshape Data Dump
Status Description
1111 0000 System Exclusive (SysEx)
0000 0001 DSI ID
0010 0000 Evolver ID
0000 0001 File Version
0000 1010 Waveshape Data
0vvv vvvv Waveshape number, 0 – 127, corresponds to Waveshapes 1 – 128. Only
Waveshapes 96 – 127 can be sent to Evolver and saved as user
programmable; others will be ignored.
0vvv vvvv 293 bytes in “packed MS bit” format (see page 60). The 293 bytes = 256
data bytes, in the format of LS byte/MS byte, for the 128 16-bit words that
make up a waveshape. The ROM Waveshapes are 12 bit two’s
complement (to match the VS), but the User Waveshapes (97 – 128) can
be a full 16 bits.
1111 0111 End of Exclusive (EOX)
