-9-
PREPARATIONS
Description
4200H 4200HV
Slope/Grade Capability Dual (±10.00%) Dual (±10.00%)
Power Supply 4-C Cell, NiMh
Rechargeable Approx.
50hr.(Ni-MH);
Approx. 40hr (Alkaline)
4-C Cell, NiMh
Rechargeable Approx.
50hr.(Ni-MH);
Approx. 40hr (Alkaline)
Water/Dust Protection IP55 IP55
Dimension 6.3 x 6.3 x 7.8-in
(160 x 160 x 198mm)
6.3 x 6.3 x 7.8-in
(160 x 160 x 198 mm)
Weight: 4.5 lb (2.0kg) 4.5 lb (2.0kg)
Inserting/Replacing Battery
Rechargeable or alkaline battery
packs are suitable for use to power
your instrument.
!
WARNING
Always replace all
alkaline batteries at
the same time. Only use batteries
from one brand and with the identical
capacity.
Remove the batteries/pack from the
tool when not using it for extended
periods. When storing for extended
periods, the batteries can corrode and
discharge themselves.
Un-screw the bolt at the bottom of
instrument base. Remove the battery
pack.
Use either alkaline battery or Ni-Mh
battery pack. When inserting
alkaline batteries, pay attention to
the correct polarity according to the
representation on the inside of the
battery compartment. Always replace
all batteries at the same time. Only
use batteries from one brand and
with the identical capacity.
When installing the battery pack
onto base, be certain that electrode
connection align properly. Secure by
tighten the bolt onto the bottom of
instrument base.
Remove the batteries from the
tool when not using it for extended
periods. When storing for extended
periods, the batteries can corrode
and discharge themselves.
